FDM Material Data Sheet
ADDITIVE+
PETG-HF
FDM · Fused Deposition Modeling · Tough, chemical-resistant
High-flow tough PETG — impact- and chemical-resistant for enclosures and functional parts.
ProcessFDM
Tensile streng50
Heat deflectio70
Min order$50
Typical properties
| Property | Typical value | Unit |
|---|---|---|
| Density | 1.27 | g/cm³ |
| Tensile strength | 50 | MPa |
| Elongation at break | 25 | % |
| Flexural modulus | 2.1 | GPa |
| Heat deflection (HDT) | 70 | °C |
| Chemical resistance | Good | — |
Typical applications
Electronics enclosuresFluid-contact housingsImpact-loaded coversFunctional prototypes
Process capability
| Spec | Value | Unit |
|---|---|---|
| Layer height | 100–300 | µm |
| Typical tolerance | ±0.3–0.5 | mm |
| Min wall thickness | 1.0–1.2 | mm |
| Min feature | 1.0 | mm |
| Build envelope | engineer | confirmed |
Note on values. Figures are typical reference values for this thermoplastic family and are given for design guidance only — they are not lot-specific certified data and vary with print orientation, layer height, infill and wall count. FDM parts are anisotropic: strength along the layers is higher than across them, so orientation is set for the load case. Confirm critical values with your applications engineer before designing to them.
