FDM Material Data Sheet
ADDITIVE+
TPU-95A
FDM · Fused Deposition Modeling · Flexible, rubber-like
Flexible, rubber-like elastomer for gaskets, grips, bumpers and living hinges.
ProcessFDM
Shore hardness95
Abrasion resisHigh
Min order$50
Typical properties
| Property | Typical value | Unit |
|---|---|---|
| Density | 1.21 | g/cm³ |
| Shore hardness | 95 | A |
| Tensile strength | 35 | MPa |
| Elongation at break | 500 | % |
| Abrasion resistance | High | — |
| Rebound elasticity | Good | — |
Typical applications
Gaskets & sealsGrips and handlesBumpers & dampersLiving hinges
Process capability
| Spec | Value | Unit |
|---|---|---|
| Layer height | 100–300 | µm |
| Typical tolerance | ±0.3–0.5 | mm |
| Min wall thickness | 1.0–1.2 | mm |
| Min feature | 1.0 | mm |
| Build envelope | engineer | confirmed |
Note on values. Figures are typical reference values for this thermoplastic family and are given for design guidance only — they are not lot-specific certified data and vary with print orientation, layer height, infill and wall count. FDM parts are anisotropic: strength along the layers is higher than across them, so orientation is set for the load case. Confirm critical values with your applications engineer before designing to them.
