Technical Data Sheet
SLS · Bio-based Polyamide
PA11 Bio-Nylon
Nylon 11 · Bio-based (castor oil) · PA11
Bio-based nylon 11 — highly ductile and impact-resistant, from renewable castor oil. For snap-fits, clips, prosthetics and parts that must flex without breaking.
SLS
PA11
PA11~45 %Elongation
~48 MPaTensile strength
~1600 MPaTensile modulus
1.02 g/cm³Density
Material overview
PA11 is a bio-based nylon derived from renewable castor oil. It offers markedly higher ductility and impact resistance than PA12 with excellent fatigue life — ideal for parts that flex repeatedly or absorb impact without cracking. It prints support-free with a natural matte finish, and is common in snap-fits, clips, sports gear, orthotics and prosthetics, and living-hinge parts.
Highlights
- Very ductile — ~45% elongation
- Excellent impact & fatigue life
- Bio-based — renewable feedstock
- No supports — complex geometry free
Ideal applications
Snap-fits & clipsSports & wearablesOrthotics / prostheticsLiving hingesAutomotiveDucting
Mechanical properties
| Property | Value | Unit |
|---|---|---|
| Elongation at break | ~45 | % |
| Tensile strength | ~48 | MPa |
| Tensile modulus | ~1600 | MPa |
| Flexural modulus | ~1400 | MPa |
| Charpy impact (unnotched) | No break | — |
| Hardness | ~75 | Shore D |
Physical & thermal
| Property | Value | Unit |
|---|---|---|
| Density (part) | ~1.02 | g/cm³ |
| Melting point | ~186–201 | °C |
| HDT (0.45 MPa) | ~150 | °C |
| Layer thickness | 60–120 | µm |
| Feedstock | Bio-based | — |
| Powder PSD | ~55 | µm |
