Technical Data Sheet
SLS · Polyamide
PA12 Nylon
Nylon 12 · PA2200-class · ISO 1874-PA12
The general-purpose SLS powder — strong, near-isotropic, printed with no supports. The versatile default for functional enclosures, ducts, jigs and low-volume production.
SLS
PA12
PA12~48 MPaTensile strength
~1700 MPaTensile modulus
~18 %Elongation
0.93 g/cm³Density
Material overview
PA12 (nylon 12) is the workhorse SLS powder. Laser-sintered fully without supports, it produces tough, near-isotropic parts with a uniform matte finish, good chemical resistance and biocompatible / skin-contact grades. It is the default choice for functional prototypes, enclosures, ducting, jigs and small-batch end-use parts — and takes dyeing, vapor smoothing and painting cleanly.
Highlights
- No supports — complex geometry & internal channels
- Near-isotropic strength (XY & Z)
- Biocompatible skin-contact grades
- Finish: dye · vapor-smooth · paint
Ideal applications
EnclosuresDuctingFunctional prototypesJigs & fixturesLow-volume productionAutomotive
Mechanical properties
| Property | Value | Unit |
|---|---|---|
| Tensile strength | ~48 | MPa |
| Tensile modulus | ~1700 | MPa |
| Elongation at break (XY) | ~18 | % |
| Elongation at break (Z) | ~6 | % |
| Flexural modulus | ~1500 | MPa |
| Charpy impact | ~4.4 | kJ/m² |
| Hardness | ~75 | Shore D |
Physical & thermal
| Property | Value | Unit |
|---|---|---|
| Density (part) | 0.93–1.0 | g/cm³ |
| Melting point | ~176 | °C |
| HDT (0.45 MPa) | ~160 | °C |
| HDT (1.8 MPa) | ~95 | °C |
| Layer thickness | 60–120 | µm |
| Powder PSD | ~56 | µm |
AADDITIVE+
Innovate. Create. Print the Future.
additiveplus.com · [email protected] · +1 (747) 800-4854 · Gardena, CA · USAScan to request a quote
Property data per the material manufacturer’s technical datasheet and industry references (on file). Values are indicative and may vary with machine, parameters, orientation and post-processing — not a guaranteed specification or a legally binding MSDS; SDS available on request. © 2019–2026 Additive Plus · All rights reserved. AO Metal is our trademark.
