In stock
M.A.T. — Paste / DIW Robocasting Head
Two-fluid DIW / robocasting head for the 3DCeram M.A.T. — mix two materials, print ceramic slurry or silicone.
- ✓ Mixing 1:1–5:1 · 2×55 mL · up to 6 bar
- ✓ Two-fluid or single-fluid · fine, complex geometries
- ✓ Customer-developed feedstock · installs on your M.A.T.
Add-on for the 3DCeram M.A.T. · requires the base system · made to order
$27,000
Robocasting on the M.A.T. — ceramic slurry, silicone, and two materials in one print.
The Two-Fluid Direct Ink Writing (DIW / robocasting) head extrudes paste feedstock and blends two materials in a single nozzle — for functionally graded parts, fine complex geometries, and silicone. It also runs as a single-fluid head. Feedstock is customer-developed (3DCeram does not supply DIW feedstock).
Specifications
| Technology | Two-fluid Direct Ink Writing (robocasting) |
| Materials | Ceramic slurry / silicone — customer-developed feedstock |
| Mixing ratio | 1:1 to 5:1 |
| Cartridges | 2 × 55 mL |
| Dosing | 0.03 mL / rev |
| Max. flow rate | 3.3 mL / min |
| Max. pressure | 6 bar |
| Modes | Two-fluid or single-fluid |
| Compatible with | 3DCeram M.A.T. |
| Part number | C0030032 |
What it’s for
Research and production teams working with robocasting, functionally graded materials, two-material structures, or silicone — where filament and pellet extrusion can’t go.
How you buy
- Made to order with your M.A.T. — installed & commissioned by Additive Plus
- US service, spares & technical support — official 3DCeram US representative
- Leasing & installment available · mutual NDA before any file review
Other products teams run alongside M.A.T. — Paste / DIW Robocasting Head
Dual-head frame reinforcement for the 3DCeram M.A.T. — mount two FFF or two DPE heads for bi-material printing.
- ✓ Two heads mounted simultaneously
- ✓ Bi-material printing in a single build
- ✓ Specified & fitted by Additive Plus
Add-on for the 3DCeram M.A.T. · requires the base system · made to order
In stock
Replacement light-engine protective glass for Nexa3D NXE printers with the LE5 light engine (NX Pro generation). The glass shields the projector optics from resin and debris; a scratched or fouled pane scatters light and softens prints, so swapping it restores clean projection.
- ✓ Protective glass for the NXE LE5 / NX Pro light engine
- ✓ Match your light-engine generation before ordering (LE1–LE4 uses a different kit)
- ✓ Genuine Nexa3D kit (P/N 12018) · currently on backorder — contact us for lead time
Out of stock
· Out of stock — send us a request and we will check availability
Single heating resistance for the Zetasinter chamber furnace.
- ✔ One resistance per unit — order the quantity your furnace needs
- ✔ Genuine Zetamix by Nanoe component
- ✔ Wear part on any resistance-heated furnace
In stock
· Ships from California · 10–20 business days
Desktop 2-in-1 station that dries four filament spools and anneals printed parts up to 100°C — heat-radiation drying with feed-through ports so filament stays dry while you print.
- ✓ Dries four spools at once — feed-through ports keep filament dry mid-print
- ✓ Anneals printed parts up to 100°C to relieve internal stress and improve strength
- ✓ Preset filament profiles (PLA to PEEK/CF) auto-set the drying temperature
- ✓ Lead time: 2–3 weeks — ships to order
Made to order
· Lead time: 2–3 weeks — ships to order
Turn the F-NIS 23151 already in your lab into Version E: a second printhead, so two materials print in one job.
- Two pneumatic heads, independent pressure for each cartridge
- Independent heating up to 60 °C for each cartridge
- Shared UV 365/405 nm · 120 °C glass platform kept
- Lead time 2–3 weeks · remote commissioning · 12-month warranty
Made to order
· Ships in 2–3 weeks
Replacement resin vat for the Nexa3D XiP — the tray that holds resin over the masking LCD and carries the membrane the print peels from each layer. As the membrane clouds or wears, print quality drops; a fresh vat restores clean, consistent layers.
- ✓ Resin vat assembly for the XiP LSPc engine
- ✓ Direct fit for the Nexa3D XiP desktop printer
- ✓ Genuine Nexa3D part · ships in 2 business days
In stock
· 2 Business Days
Print temperature-sensitive pastes on your Sygnis F-NIS 23151: the Heat Module warms a 10 ml cartridge to 60 °C and turns a Version B into a Version C.
- Heated 10 ml cartridge head, up to 60 °C
- Upgrades F-NIS Version B to Version C — self-installed
- 12-month Sygnis warranty · online setup support
- Ships in 2–3 weeks
Made to order
· Ships in 2–3 weeks
Eight-colour glaze kit for finishing parts printed in Zetamix Porcelain filament.
- ✔ Eight colours in one kit
- ✔ Made for parts printed and fired in Zetamix Porcelain
- ✔ Genuine Zetamix by Nanoe
In stock
· Ships from California · 10–20 business daysWhat our customers say
“Harry and team were professional, effective communicators as we set up the order, then they executed quickly and produced an amazing product for us at a very competitive price. Am looking forward to our next print w Additive Plus!”
“Great 3D printing service and the resin parts look super smooth and clean. Really happy with how everything turned out!”
“Harry was very professional and helped me out with my 3D printing needs and explained what options I have in terms of filaments such as PEEK. Highly recommended.”
“I needed a 3D enclosure printed urgently in a specific time period, they did great!”
Place your order, or talk to an engineer first
Order M.A.T. — Paste / DIW Robocasting Head direct, or talk to materials engineer
