CreatBot PVDF Filament – 1kg
Industrial-grade PVDF filament with outstanding chemical and heat resistance for demanding applications in aggressive environments.
-
Type:
Plastic Filaments
In stock
- Description
- Details
- Materials
- Documents
- Videos
- Review
Description
PVDF (Polyvinylidene Fluoride) is a premium high-performance polymer engineered for the most demanding industrial applications. This specialty PVDF filament delivers exceptional resistance to chemicals, heat, and wear while maintaining excellent mechanical strength, making it ideal for components that operate in aggressive environments where other materials would fail.
Key Features & Benefits
-
Exceptional Chemical Resistance: Withstands acids, solvents, and hydrocarbons without degradation
-
Outstanding Heat Resistance: High heat deflection temperature of 158°C for elevated temperature applications
-
Excellent Mechanical Properties: Strong, stiff, and durable with good impact resistance
-
Low Moisture Absorption: Maintains dimensional stability in humid environments
-
UV and Weather Resistance: Suitable for both indoor and outdoor applications
Recommended Print Settings
| Parameter | Recommended Value |
|---|---|
| Nozzle Temperature | 245°C – 265°C |
| Build Plate Temperature | 90°C – 110°C |
| Chamber Temperature | Not Required |
| Print Speed | 40 – 60 mm/s |
| Cooling Fan | OFF |
| Nozzle Type | Standard Brass Nozzle |
Performance Highlights
-
Chemical Resistance: Exceptional – Superior to most 3D printing materials
-
Heat Resistance: Outstanding (158°C HDT)
-
Mechanical Strength: High – Good balance of strength and stiffness
-
Durability: Excellent – Resists wear and environmental stress
Typical Applications
-
Chemical Processing Equipment
-
Pipes, Valves, and Fittings
-
Electrical Insulation Components
-
Medical and Laboratory Equipment
-
Aerospace and Automotive Components
-
Outdoor and Marine Applications
Storage & Handling
Store Creatbot PVDF Filament in a cool, dry place inside its original sealed bag with desiccant. For long-term storage or in humid environments, use a dry box to prevent moisture absorption, which can lead to printing issues and reduced mechanical properties.
- Brand CreatBot
- Printing Materials Plastic Filaments
- Solid Density g/cm3 1.71
- Tensile Strength 51
- Tensile Modulus (MPa) 2450
- Flexural Strength (MPA) 80
- Flexural Modulus (MPa) 1800
- Deflection Temperature 158
- Printer CreatBot F430
- Nozzle Temperature 260℃
- Bed Temperature 90℃
- Printing Speed 40mm/s
- Infill 100%，+/- 45°
- Nozzle size 0.4mm
- Layer thickness 0.2mm
