In stock
- Lot-matched resin sealed and batch-traceable for repeatable prints
- Validated LSPc profile exposure and cure settings for your Nexa3D printer
Nexa3D xMODEL35-Black Resin – Rigid High-Temp Photopolymer for XiP | 1.5 kg
What your process engineer actually checks
Numbers you can design to
Every value on this card comes from the official Nexa3D xMODEL35 technical data sheet with the ASTM method named next to it — 87 °C HDT at 1.82 MPa, 2300 MPa flexural modulus, 83 D Shore hardness. No rounded-up figures, and legacy numbers from older sheets are not reused.
A materials engineer on the line
Questions on cure settings, finishing or switching from another resin? Our engineers run Nexa3D LSPc resins in-house. Sub-4h reply, NDA standard.
Nexa3D xMODEL35-Black is a rigid, high-performance LSPc photopolymer that combines strength, stiffness and temperature resistance in a single 1.5 kg cartridge for XiP and XiP Pro. With 87 °C HDT at 1.82 MPa and a 2300 MPa flexural modulus, it is the grade to reach for when a printed model, jig or light end-use part has to hold its shape under load and warmth.
Why engineers choose xMODEL35
Published ASTM data from the Nexa3D technical data sheet — not marketing estimates.
87 °C HDT at 1.82 MPa
Parts stay dimensionally honest in warm fixtures, under lamps and through heated finishing steps that soften general-purpose model resins.
2300 MPa flexural modulus
Stiff enough for snap-fit housings and locating jigs, with 108 MPa flexural stress and 53 MPa ultimate tensile strength.
21 / 112 J/m IZOD impact
Notched and unnotched values per ASTM D256, with 9% elongation at break — rigid, but not glassy in normal handling.
630 cP at 30 °C
Low viscosity recoats and drains quickly in LSPc printing, and UL94 HB at 1.5 mm is documented for enclosure work.
How we supply xMODEL35
From Nexa3D formulation to a cured part on your bench.
Formulated & tested
Nexa3D formulates xMODEL35 for 405 nm LSPc and publishes ASTM D638, D790, D256 and D648 data, so you design to measured numbers.
Stocked & lot-matched
We hold xMODEL35-Black 1.5 kg cartridges in US stock, sealed and batch-traceable, and dispatch in 2 business days.
Print, wash & cure
Load the cartridge in XiP or XiP Pro, wash in xClean then IPA, dry, and post-cure to reach the published properties.
Physical and mechanical properties
| Property | Method | Value |
|---|---|---|
| Young’s modulus | ASTM D638 | 1765 MPa |
| Ultimate tensile strength | ASTM D638 | 53 MPa |
| Elongation at break | ASTM D638 | 9% |
| Viscosity, 25 °C | ASTM D7867 | 950 cP |
| Viscosity, 30 °C | ASTM D7867 | 630 cP |
| Flexural modulus | ASTM D790 | 2300 MPa |
| Flexural stress | ASTM D790 | 108 MPa |
| IZOD impact (notched / unnotched) | ASTM D256 | 21 / 112 J/m |
| HDT @ 0.45 MPa | ASTM D648 | 64 °C |
| HDT @ 1.82 MPa | ASTM D648 | 87 °C |
| Glass transition (DMA tan δ) | ASTM D4065 | 112 °C |
| Shore hardness | ASTM D2240 | 83 D |
| Water absorption (24 h) | ASTM D570 | 0.42% |
| Flammability | UL94 | HB (1.5 mm) |
| Liquid density | ASTM D4052 | 1.11 g/cm³ |
Printed properties depend on part geometry, orientation and post-cure. Values are typical, not a specification.
Typical applications
Where the stiffness and heat numbers actually earn their keep.
Compatible printers & post-processing
This 1.5 kg cartridge of xMODEL35-Black is made for the Nexa3D XiP and XiP Pro desktop LSPc printers. The same resin is also sold as a 5 kg bottle, which additionally feeds the NXE 400 and NXE 400 Pro. After printing, wash parts in xClean for no more than 2 minutes, follow with an IPA rinse of no more than 5 minutes, then dry fully before curing. Post-cure for 2 × 30 minutes in the XiP Cure unit, or a single 60-minute cycle in xCURE. The values in the table are measured on fully cured specimens, so a shortened cure will leave parts softer and lower in HDT than the data sheet suggests.
Not sure xMODEL35 is the right resin?
Three neighbours in the Nexa3D LSPc line, depending on budget, application and package size.
Why source xMODEL35 through Additive Plus
- Genuine Nexa3D xMODEL35-Black — lot-matched, US stock, ships in 2 business days
- Validated LSPc exposure and cure profiles for XiP and XiP Pro
- Materials engineers who run these resins in-house — sub-4h reply, NDA standard
- Volume pricing and official purchase orders supported for production accounts
Downloads
| Brand | Nexa3D |
| Available colors | Black |
| Weight | 1.5 kg |
| Country of origin | USA |
| Printing Materials | Resins |
| Technology | LSPc |
| Package | 1.5 kg cartridge |
| Material form | Liquid photopolymer resin |
| Printer | XiP, XiP Pro |
| Tensile Strength | 53 MPa |
| Tensile Modulus (MPa) | 1765 MPa |
| Elongation at Break (%) | 9% |
| Shore Hardness (3s) | 83 D |
| [email protected] MPA (°C) | 64 °C |
| Water Absorption (24hr) % | 0.42% |
| Flexural Modulus (MPa) | 2300 MPa |
| Flexural Strength (MPA) | 108 MPa |
| IZOD Impact (Notched, J/m) | 21 J/m |
| Resin Type | General, High-temp, Rigid |
| Application | Engineering, Manufacturing |
