CreatBot Ultra PA CF - Glass Fiber Nylon Filament - 1kg
PA GF glass fiber reinforced nylon delivers high strength, stiffness and heat resistance for demanding industrial applications and functional parts.
$93
Price held 7 days after order.
NDA standard
Ships in 1–2 business days
Built for production teams
What your process engineer actually checks
Tight diameter, dry, jam-free
Every spool ships with a datasheet covering diameter tolerance, moisture, and a validated print profile for the systems we sell, so feeds stay consistent and parts hold dimension. Load the profile and print.
A materials engineer on the line
Questions on diameter tolerance, moisture, layer adhesion, or warping? A materials engineer answers directly — not a contact-form bot. Most replies in under 4 hours, NDA standard.
About this product
Creatbot Ultra PA GF (Glass Fiber Reinforced Polyamide) is an engineering-grade composite filament that combines high-temperature nylon with 15% glass fiber reinforcement. This advanced PA GF material delivers superior mechanical properties, excellent thermal stability, and reduced warping compared to standard nylons, making it ideal for demanding industrial applications.
Key Features & Benefits
-
High Strength & Stiffness: Glass fiber reinforcement provides excellent tensile strength (88 MPa) and flexural modulus (4852 MPa)
-
Superior Heat Resistance: High heat deflection temperature (101°C) ensures performance in elevated temperature environments
-
Enhanced Dimensional Stability: Reduced shrinkage and warping during printing compared to unreinforced nylons
-
Excellent Layer Adhesion: Strong interlayer bonding for durable, reliable parts
-
Good Chemical Resistance: Suitable for applications exposed to various chemicals and fuels
Recommended Print Settings
| Parameter | Recommended Value |
|---|---|
| Nozzle Temperature | 280°C – 320°C |
| Build Plate Temperature | 70°C – 80°C |
| Chamber Temperature | 50°C or Off |
| Print Speed | 30 – 60 mm/s |
| Cooling Fan | OFF or Low |
| Nozzle Type | Hardened Steel Nozzle |
Performance Highlights
-
Mechanical Strength: High (88 MPa tensile, 141 MPa flexural)
-
Stiffness: Excellent (4852 MPa flexural modulus)
-
Heat Resistance: Very Good (101°C HDT)
-
Dimensional Stability: Superior to standard nylons
Typical Applications
-
Automotive Components & Under-hood Parts
-
Aerospace Brackets & Mounts
-
Industrial Jigs, Fixtures & Tooling
-
Consumer Electronics Housings
-
Mechanical Components & Gears
-
Functional Prototypes & End-Use Parts
Storage & Handling
Store Creatbot Creatbot Ultra PA GF (Glass Fiber Nylon Filament) in a cool, dry place inside its original sealed bag with desiccant. For long-term storage or in humid environments, use a dry box to prevent moisture absorption, which can lead to printing issues and reduced mechanical properties.
| Brand | CreatBot |
| Printing Materials | Plastic Filaments |
| Solid Density g/cm3 | 1.16 |
| Tensile Strength | 88 |
| Tensile Modulus (MPa) | 4833 |
| Flexural Strength (MPA) | 141 |
| Flexural Modulus (MPa) | 4852 |
| Deflection Temperature | 101, 135 |
| Glass Transition Temperature | 147 |
| Printer | CreatBot F430 |
| Nozzle Temperature | 300°C |
| Bed Temperature | 80°C |
| Printing Speed | 40mm/s, 45mm/s |
| Infill | 100%，+/- 45° |
| Nozzle size | 0.4mm |
| Layer thickness | 0.2mm |
