Loctite 3D IND3380 ESD Black 1 kg

$360

ESD-safe black resin (HDT190°C): Precision tooling for electronics. Electrostatic dissipation.

  • In stock

$360

Need an official request?

  • Description
  • Details
  • Materials
  • Documents
  • Videos
  • Review

Description

Engineered for Demanding Industrial Environments
LOCTITE 3D IND3380 ESD Black revolutionizes functional 3D printing with its unique triple-threat capabilities: electrostatic dissipation (ESD), extreme heat resistance (190°C HDT), and industrial-grade stiffness. This advanced photopolymer delivers precision tooling solutions for electronics manufacturing, aerospace, and automotive sectors where static sensitivity and thermal stability are non-negotiable.

Applications

Electronics Manufacturing

  • ESD-safe fixtures for PCB assembly
  • Conformal coating masks
  • Sensor calibration jigs

High-Temp Tooling

  • Composite layup molds
  • SMT stencil frames
  •  Automotive under-hood components

Precision Components

  • Semiconductor handling tools
  •  Vacuum chamber fixtures
  • Metrology equipment bases

Why IND3380 Outperforms

  • ESD Reliability: Maintains resistivity range across geometries (unlike carbon-filled composites)

  • Thermal Stability: 40% higher HDT than standard industrial resins

  • Production-Ready: Achieves UL-recognized properties with certified workflow

  • Material Economy: 1.20–1.25 g/cm³ density reduces part cost vs. metals

Industrial Certification: DIN EN61340-2-3 ESD | RoHS/REACH Compliant | Validated per ASTM D638/D790/D648

  • Brand Henkel Loctite
  • Available colors Black
  • Print Feature High Temp
  • Young's Modulus (MPa) 1300 – 1500 / 2800 – 3000
  • Tensile Stress at Break (MPa) 25 – 30 / 40 – 50
  • Elongation at Break (%) 2 – 3 / 1 – 2
  • Flexural Modulus (MPa) 1250 – 1350 / 3200 – 3400
  • Shore Hardness (3s) 86.5
  • IZOD Impact (Notched, J/m) 11.5 – 12.5
  • Water Absorption (24hr) % <0.4
  • Solid Density g/cm3 1.20 – 1.25
  • Heat Capacity J/(g*K) 0.2
  • Viscosity at 25°C (77°F) cP 1000-1800, 9000 - 11000
  • Liquid Density g/cm³ 1.1-1.2
  • HDT@0.46 MPA (°C) 180 – 190
  • HDT at 1.82 MPa 100 – 110
