ELTRA CS-580A Carbon/Sulfur Combustion Analyzer – C & S, TOC/TIC | 0.005–100%
Combustion analyzer for the simultaneous determination of carbon and sulfur — the sample is burned in a resistance furnace up to 1,550 °C and measured by up to four infrared cells, covering 0.005–100 % in 60–120 seconds.
- ✔ C / S + TOC / TIC · 0.005–100 % · single or multi-element
- ✔ Resistance furnace to 1,550 °C (1 °C steps) · up to 4 IR cells · gold IR path
- ✔ 50–500 mg samples · optional 36/130-position autoloader (acid-resistant)
- ✔ Lead time: configured to order — request current timeline
Price held 7 days after order.
Install + training included
Tailored service plan
Built for materials QC teams
What your QC lab actually checks
Simultaneous C/S over a wide range
Combustion in a resistance furnace adjustable to 1,550 °C, with up to four solid-state infrared cells, determines carbon and sulfur simultaneously from 0.005 % up to 100 % in 60–120 seconds. Single-element (C or S) or combined C/S configurations, plus TOC to DIN EN 15936 and an optional TIC module, cover organic and inorganic matrices from one bench.
An applications engineer on the line
IR-cell configuration, calibration, blank control and TOC/TIC method setup from engineers who run materials characterization in-house. Sub-4h reply, NDA standard.
About this product
The ELTRA CS-580A is a combustion analyzer for the simultaneous determination of carbon and sulfur in organic and inorganic samples. The sample is burned in an oxygen atmosphere in a resistance furnace adjustable up to 1,550 °C in 1 °C steps; the combustion gases (CO₂, SO₂) are dried and measured in up to four solid-state infrared cells. It covers 0.005–100 % as a single element (C or S) or a combined C/S configuration, accepts 50–500 mg sample weights, and supports TOC to DIN EN 15936 plus an optional TIC module.
Why QC and materials labs choose the CS-580A
Simultaneous carbon and sulfur analysis over a wide concentration range, from trace to 100 %.
Simultaneous C/S in 60–120 s
Fast, simultaneous determination of carbon and sulfur over 0.005–100 % — configurable for a single element (C or S) or combined C/S analysis.
Up to four infrared cells
Combine multiple solid-state IR cells with different sensitivities, plus a gold IR path, for a wide dynamic range on both trace and very high sulfur levels.
TOC & TIC ready
Runs TOC analysis to DIN EN 15936 with an optional acid-resistant autosampler, and adds an optional TIC module for total inorganic carbon.
High-throughput autoloader
An optional 36- or 130-position autoloader — including an acid-resistant version — keeps high sample volumes running with minimal operator attention.
How Additive Plus supports it
A configured, installed analyzer with a carbon/sulfur method dialed in on your samples.
Step 01
Configure to your samples
We spec the C/S configuration, IR cells, TIC module and autoloader to your matrix and concentration range before it ships.
Step 02
Install & train
Factory-trained engineers install the analyzer, connect oxygen, air and the PC/balance, and train your team on weighing and analysis.
Step 03
Method & QC support
We help build the SOP — calibration with standards, blank control, TOC/TIC method and a repeatable carbon/sulfur baseline.
What the CS-580A measures
Full technical specifications are in the Specifications tab. Key measurement capability:
| Parameter | CS-580A |
|---|---|
| Measured elements | Carbon, sulfur (+ TOC / TIC) |
| Concentration range | 0.005–100 % |
| Principle | Combustion (resistance furnace to 1,550 °C, 1 °C steps) + solid-state infrared absorption |
| Detection | 1–4 infrared cells · gold IR path |
| Sample weight | 50–500 mg · ceramic crucibles |
| Analysis time | ~60–120 seconds |
| Requirements | Oxygen 99.5 % · compressed air · PC, monitor, 0.0001 g balance |
Typical sample materials
Where carbon and sulfur have to be quantified across organic and inorganic matrices.
Coal & coke
Fuel and process QC
Soil & plant material
TOC and agriculture
Building materials
Gypsum, limestone, cement
Rubber & plastics
Sulfur and carbon control
Oil & waste
Sulfur and carbon content
Ash, sand & soot
Residual carbon / sulfur
Not sure the CS-580A is the right analyzer?
Compare with other ELTRA combustion analyzers in our catalog.
Adds hydrogenELTRA CHS-580AView analyzer →
C/S resistanceELEMENTRAC CS-rView analyzer →
Metals / inductionELEMENTRAC CS-iView analyzer →
C/S resistanceELEMENTRAC CS-rView analyzer →
Metals / inductionELEMENTRAC CS-iView analyzer →
Tell us your sample matrix and the carbon and sulfur range you need to control — our applications engineer will confirm the right CS-580A configuration (IR cells, TIC module, autoloader) and calibration approach. Sub-4h reply, NDA standard.
Why source the CS-580A through Additive Plus
- Authorized channel for ELTRA / Verder Scientific lab equipment — sales, installation, training and service in one place.
- Configured to your samples — C/S setup, IR cells, TIC module and autoloader specified before shipping.
- Method development on your samples — calibration, blank control and a repeatable carbon/sulfur / TOC SOP.
- <24h response from engineers who run materials characterization in-house. NDA standard.
| Brand | ELTRA |
| Model | CS‑580A |
| Measured elements | carbon, sulfur |
| Samples | organic |
| Furnace alignment | vertical |
| Sample carrier | ceramic crucibles |
| Field of application | agriculture, biology, chemistry / plastics, coal / power plant, construction materials, environment / recycling, medicine / pharmaceuticals |
| Furnace | resistance furnace (ceramic tube), adjustable up to 1550 °C (steps of 1 °C) |
| Detection method | solid state infrared absorption |
| Number of IR cells | 1 - 4 |
| Material of IR path | gold |
| Typical analysis time | 60 - 120 s |
| Chemicals required | magnesium perchlorate, sodium hydroxide |
| Gas required | oxygen 99.5 % pure (2 - 4 bar / 30 - 60 psi) compressed air (4 - 6 bar / 60 - 90 psi) |
| Power requirements | 230 V, 50/60 Hz max. heat up current 2000 W |
| Dimensions (W x H x D) | 550 x 1000 x 600 mm / 21.65 x 39.37 x 23.62 in (analyzer) 850 x 350 x 450 mm / 33.46 x 13.78 x 17.72 in(Autoloader for 130 crucibles) |
| Weight | ~ 90 kg (analyzer) ~ 15 kg (Autoloader for 130 crucibles) |
| Required equipment | PC, monitor, balance (resolution 0.0001g) |
| Optional accessories | TIC module, voltage stabilizer 5 KVA |
Product videos
Other products teams run alongside ELTRA CS-580A Carbon/Sulfur Combustion Analyzer – C & S, TOC/TIC | 0.005–100%
Analysis equipment
ELTRA CW-800M Multi-Ramp CO₂ & Water Analyzer – TOC/TIC Acid-Free | Cement, Soil & Waste
Multi-ramp version of the CW-800 for simultaneous carbon dioxide and water — up to five programmable temperature steps release and resolve TOC/TIC and water fractions without adding acids, measured by infrared cells.
- ✔ CO₂ + water · TOC / TIC without acids · fraction "chromatogram"
- ✔ Up to 5 programmable ramps · resistance furnace to 1,000 °C · 1–2 IR cells
- ✔ Nitrogen & oxygen carrier · gold IR path · no halogen trap
- ✔ Lead time: configured to order — request current timeline
In stock
· Lead time: configured to order — request current timeline
Analysis equipment
ELTRA CW-800 CO₂ & Water Analyzer – Simultaneous IR | Gypsum, Cement & Minerals
Analyzer for the simultaneous determination of carbon dioxide and water — the sample in a quartz boat is heated in a resistance furnace up to 1,000 °C, and released CO₂ (from carbonates) and water are measured by infrared cells in 2–3 minutes.
- ✔ CO₂ + H₂O simultaneously · minimal sample prep
- ✔ Resistance furnace to 1,000 °C (1 °C steps) · 1–2 IR cells · gold IR path
- ✔ Nitrogen carrier · no halogen trap · single/multipoint calibration
- ✔ Lead time: configured to order — request current timeline
In stock
· Lead time: configured to order — request current timeline
Analysis equipment
ELTRA ELEMENTRAC CS-i Induction Carbon/Sulfur Analyzer – Metals & Ceramics | 0.6 ppm–6%+
Induction-furnace analyzer for carbon and sulfur in inorganic samples and metals — combustion above 2,000 °C with up to four infrared cells covering 0.6 ppm to more than 6 % at 1,000 mg, in about 40 seconds.
- ✔ Induction furnace > 2,000 °C · single or simultaneous C/S · metals & inorganics
- ✔ 0.6 ppm to 6 %+ · up to 4 IR cells · heated dust trap · Pt catalyst
- ✔ ~40 s analysis · optional 36/130-position autoloader · TIC module
- ✔ Lead time: configured to order — request current timeline
In stock
· Lead time: configured to order — request current timeline
Analysis equipment
ELTRA ELEMENTRAC OH-p 2 Oxygen/Hydrogen Analyzer – Inert Gas Fusion | Steel, Metals & Ceramics
Inert-gas-fusion analyzer for oxygen and total hydrogen in metals — the sample melts in a graphite crucible in an 8.5 kW impulse furnace above 3,000 °C, with IR detection of oxygen and thermal conductivity for hydrogen.
- ✔ O / H by fusion · single or combined OH · inorganic samples
- ✔ 8.5 kW impulse furnace > 3,000 °C · closed gas system · low detection limits
- ✔ Up to 2000 mg · nitrogen carrier · Schuetze reagent · Autocleaner option
- ✔ Lead time: configured to order — request current timeline
In stock
· Lead time: configured to order — request current timeline
Analysis equipment
ELTRA ELEMENTRAC CS-d Dual-Furnace Carbon/Sulfur Analyzer – Induction + Resistance | ppm–100%
Dual-furnace analyzer that combines an induction furnace (above 2,000 °C) and a resistance furnace (to 1,550 °C) in one instrument — carbon and sulfur in both inorganic and organic samples, from ppm to 100 %, with up to four gold infrared cells.
- ✔ ELTRA Dual Furnace (EDF) · induction + resistance · organic & inorganic C/S
- ✔ ppm to 100 % · up to 4 independent IR cells · gold IR path
- ✔ Intelligent lance · low-blank port · 36/130 autoloader · TIC · halogen trap
- ✔ Lead time: configured to order — request current timeline
In stock
· Lead time: configured to order — request current timeline
Analysis equipment
ELTRA ELEMENTRAC CHS-r Carbon/Hydrogen/Sulfur Analyzer – Resistance Furnace + IR | 20 ppm–100%
Resistance-furnace analyzer for fast, simultaneous carbon, hydrogen and sulfur in organic matrices — combustion up to 1,550 °C with a heated H₂O infrared cell for hydrogen and solid-gold IR cells over 20 ppm to 100 %.
- ✔ Simultaneous C / H / S · 20 ppm–100 % · high sample weights
- ✔ Resistance furnace to 1,550 °C · heated H₂O IR cell · up to 3 solid-gold IR cells
- ✔ Low-blank sample port · dual-furnace option · TIC module (DIN EN 15936)
- ✔ Lead time: configured to order — request current timeline
In stock
· Lead time: configured to order — request current timeline
Analysis equipment
ELTRA ELEMENTRAC CN-r Carbon/Nitrogen Dumas Analyzer – Protein & Nitrogen | Food, Feed & Soil
Automated Dumas analyzer for nitrogen / protein and carbon — reliable results in under three minutes with interleave processing, over 70× faster than Kjeldahl, on any solid or liquid matrix.
- ✔ Dumas nitrogen / protein + carbon · validated by AOAC, ISO, DIN, AOCS, OIV
- ✔ < 3 min · interleave analysis · TCD (N) + NDIR (C)
- ✔ Integrated PC + touchscreen · FDA 21 CFR Part 11 · CN-r or N-r
- ✔ Lead time: configured to order — request current timeline
In stock
· Lead time: configured to order — request current timeline
Analysis equipment
ELTRA TGA Thermostep ML Thermogravimetric Analyzer – Manual-Lid Moisture, Ash & Volatiles | 19 Samples
Manual-lid thermogravimetric analyzer — programmable furnace plus integrated balance measures moisture, ash and volatiles in up to 19 samples per run, 50–1,000 °C. A more economical route to standard-compliant TGA.
- ✔ 19 samples + 1 reference · 500 mg–5 g · moisture/ash/volatiles in one run
- ✔ Ceramic furnace 50–1,000 °C · N₂/O₂/air per stage · manual crucible lids
- ✔ Encapsulated balance 0.1 mg · ASTM D 7582 compliant
- ✔ Lead time: configured to order — request current timeline
On backorder
· Lead time: configured to order — request current timelineFrom QC and materials labs running the ELTRA CS-580A
Unedited feedback from combustion-analysis teams.
★★★★★
Carbon and sulfur on coal and coke in one determination, results in a couple of minutes. It runs every shift in our control lab.
MF
Markus F. QC Engineer · Energy / power plant
★★★★★
TOC on soils and building materials is routine now. The acid-resistant autoloader handles our sample volume without babysitting.
LS
Lucia S. Lab Supervisor · Environment / recycling
★★★★★
Sulfur in oil and rubber used to need a separate method. The high-range IR cells cover our full concentration span.
AR
Ahmed R. Materials Engineer · Chemistry / plastics
Common questions
Don't see yours? Email [email protected] — NDA standard, typical reply within 4 hours.
What does the ELTRA CS-580A measure?
The CS-580A simultaneously determines carbon and sulfur in organic and inorganic samples, over a wide concentration range from 0.005 % up to 100 %. It can be configured for a single element (carbon or sulfur) or for combined C/S analysis, and it also supports TOC (total organic carbon) to DIN EN 15936 and, with the optional module, TIC (total inorganic carbon).
How does the measurement work?
You weigh 50–500 mg of sample into a ceramic crucible and register it in the software. The sample is burned in an oxygen atmosphere in a resistance furnace, freely adjustable up to 1,550 °C in 1 °C steps. The combustion gases (CO₂, SO₂) pass a dust filter, the water vapor is chemically absorbed, and the dried CO₂ and SO₂ are measured in solid-state infrared cells. A determination takes about 60–120 seconds.
What concentration range and IR configuration are available?
The CS-580A covers 0.005–100 %. Up to four infrared cells with different sensitivities can be combined so that both trace and very high sulfur or carbon levels are measured accurately. Robust cells for high sulfur concentrations and a gold IR path for halogen- or acid-containing samples are available. Single- or multipoint calibration with certified standards keeps the wide working range reliable.
Can the CS-580A run TOC and TIC?
Yes. The CS-580A series is equipped for TOC analysis to DIN EN 15936, using optional acid-resistant autosamplers, and an optional TIC module adds total inorganic carbon. This makes it suitable for soils, sediments, building materials and waste where organic and inorganic carbon fractions both matter. Additive Plus configures the acid-resistant option and TIC module to your application before shipping.
What sample throughput and automation does it offer?
Typical sample weights are 50–500 mg, which lets you analyze heterogeneous samples representatively. For high throughput, an optional autoloader with 36 or 130 crucible positions runs sequences with minimal operator attention, and an acid-resistant plastic-crucible-holder version is available for aggressive matrices. Results export via LIMS, report or text file.
What does the CS-580A need to run?
It needs oxygen at 99.5 % purity (2–4 bar) and compressed air (4–6 bar), an external PC and monitor, and a balance with 0.0001 g resolution. It runs on 230 V, 50/60 Hz (max heat-up current 2,000 W), and uses magnesium perchlorate and sodium hydroxide as reagents. A 5 kVA voltage stabilizer is available for unstable supplies. The analyzer measures about 550 × 1000 × 600 mm and weighs ~90 kg.
What is the lead time, and can Additive Plus set it up?
The CS-580A is configured to order; request a quote for the current lead time. Additive Plus is an authorized ELTRA / Verder Scientific channel and handles installation, oxygen and balance connection, calibration and operator training, then helps build your carbon/sulfur and TOC SOP. You can also send a sample for a paid measurement first. Sub-4h reply, NDA standard.
