Geomagic Design X Reverse Engineering Software – Scan-to-CAD | Parametric Solid Modeling
Geomagic Design X is professional scan-to-CAD reverse-engineering software that turns 3D-scan mesh and point-cloud data into a feature-based, parametric CAD model — a path to CAD 3 to 10 times faster than traditional tools, with patented LiveTransfer output straight into SOLIDWORKS, Siemens NX, Solid Edge, Autodesk Inventor, and PTC Creo.
- ✓ Mesh & point cloud to parametric CAD · Auto Surface, feature-based & hybrid modeling
- ✓ Patented LiveTransfer — full feature tree into SOLIDWORKS, NX, Solid Edge, Inventor, Creo; plus neutral STEP, IGES, DXF
- ✓ Accuracy Analyzer real-time deviation check · runs on Windows 10 / 11 (64-bit)
- ✓ Delivered as a licensed download; issued to order · 14-day trial available
Price held 7 days after order.
Onboarding included
US-based support
What your design team actually checks
What your design team actually checks
A real parametric CAD model
Geomagic Design X produces a true feature-based, parametric CAD model with an editable feature tree — not a frozen mesh. Patented LiveTransfer sends it into SOLIDWORKS, NX, Solid Edge, Inventor, or Creo with history intact, and neutral STEP, IGES, and DXF cover everything else, so the rebuilt part is ready to manufacture and to modify.
An applications engineer on the line
Help with surfacing strategy, the scan-to-CAD workflow, and LiveTransfer into your CAD — from engineers who run this software. Try it on the 14-day trial first. Sub-4h reply, NDA standard.
About this product
Geomagic Design X is professional scan-to-CAD reverse-engineering software that turns 3D-scan mesh and point-cloud data into a feature-based, parametric CAD model. It processes billions of scan points with automatic and guided solid extraction — a path to CAD 3 to 10 times faster than traditional tools — and pushes finished models straight into mainstream CAD with patented LiveTransfer, or exports neutral STEP, IGES, and DXF.
Why engineers choose Geomagic Design X
A direct path from a physical part to an editable, manufacturable CAD model.
Mesh & point cloud to CAD, fast
Process billions of scan points and rebuild them into a feature-based CAD model 3 to 10 times faster than traditional tools, with automatic and guided solid extraction — no modeling a part by hand from scratch.
Feature-based, parametric history
Build with a full feature tree — extrude, revolve, loft, sweep — and blend prismatic and organic geometry in hybrid modeling. Edits stay parametric, so the rebuilt part remains editable, not frozen.
Exact & auto surfacing
Auto Surface wraps organic freeform scans with accurate exact surfaces, while the patented Accuracy Analyzer checks deviation between your model and the scan data in real time.
LiveTransfer to your CAD
Patented LiveTransfer pushes complete, editable models with full feature trees straight into SOLIDWORKS, Siemens NX, Solid Edge, Autodesk Inventor, and PTC Creo — plus neutral STEP, IGES, and DXF.
How Additive Plus delivers Geomagic Design X
Licensed, set up, and supported for your reverse-engineering workflow.
Step 01
License & install
We license Geomagic Design X for your team and get it installed, with the free trial available so you can evaluate on your own scans first.
Step 02
Train & workflow
Onboarding on the scan-to-CAD workflow — mesh cleanup, Auto Surface, feature modeling, and LiveTransfer into your CAD — so your team rebuilds parts productively from the start.
Step 03
Support that answers
Questions on a tricky surface or a specific modeling step go to engineers who run this software. Sub-4h reply, NDA standard.
From Scan to Parametric CAD
Geomagic Design X guides scan mesh and point-cloud data through cleanup and modeling into a finished, feature-based CAD solid. Mesh-editing tools handle hole filling, smoothing, and defeaturing, then Auto Surface wraps organic shapes and feature-based tools rebuild prismatic geometry against the scan. Because the result is a true parametric CAD model with an editable feature tree — not a frozen mesh — it is ready to manufacture and to modify. See the full feature list below.
LiveTransfer to Your CAD Platform
Patented LiveTransfer technology transfers complete models, including the feature tree, directly into mainstream CAD — SOLIDWORKS, Siemens NX, Solid Edge, Autodesk Inventor, and PTC Creo — with the parametric history intact, so there is no IGES/STEP re-import to rebuild. For any other package, Geomagic Design X also exports neutral STEP, IGES, and DXF. The result drops into your existing design and CAD/CAM pipeline for CNC machining, tooling, or 3D printing.
Typical applications
Reverse engineering across design and manufacturing.
Legacy part reconstruction
No-drawing parts back to CAD
Mold & tooling restoration
Rebuild worn dies and inserts
Product redesign
Modify from a physical model
Custom & aftermarket parts
Fit new parts to existing ones
CNC & 3D-print prep
Manufacturable STEP/IGES out
Inspection & QC pairing
Verify against CAD deviation
System Requirements
| Component | Recommended |
|---|---|
| Operating system | Windows 10 or Windows 11 (64-bit) |
| Processor | Quad-core CPU, 3 GHz or higher; multi-core recommended |
| Memory | 8 GB RAM minimum; 16 GB recommended |
| Graphics | Dedicated OpenGL 4.0+ GPU with 2 GB or more VRAM |
| Storage | 30 GB available disk space |
Typical workstation specification — confirm against the current vendor guide for your Design X release.
Why Source Geomagic Design X Through Additive Plus
- Authorized reseller — licensing matched to your reverse-engineering work, with a trial and a demo before you commit
- Onboarding on the scan-to-CAD workflow and LiveTransfer into your CAD included
- Application engineers who run this software — surfacing strategy and modeling help
- US-based support with a sub-4h response · 200+ scanning and AM systems delivered across 23 countries
Pair Design X with a scanner or inspection
Complete the scan → model → verify workflow.
Metrology scannerFreeScan Trak NovaView scanner →
Lite / Pro softwareSHINING3D EXModelView software →
Inspection softwareSHINING3D InspectView software →
Lite / Pro softwareSHINING3D EXModelView software →
Inspection softwareSHINING3D InspectView software →
Tell us the parts you reverse-engineer and the CAD you export to — our applications engineer will recommend the right Geomagic Design X configuration and can walk you through a sample scan-to-CAD job. Sub-4h reply, NDA standard.
| Brand | Geomagic |
| Software Type | Reverse-engineering / scan-to-CAD software |
| Technology | Feature-based & parametric reverse engineering · Auto Surface · patented LiveTransfer |
| Workflow | Mesh & point cloud to parametric CAD model · automatic and guided solid extraction |
| Modeling Tools | Mesh Buildup Wizard, mesh editing, Auto Surface, feature-based modeling (extrude, revolve, loft, sweep), hybrid modeling, Accuracy Analyzer |
| CAD Interoperability | LiveTransfer to SOLIDWORKS, Siemens NX, Solid Edge, Autodesk Inventor, PTC Creo Neutral export: STEP, IGES, DXF |
| Free Trial | 14-day free trial (on request) |
| Compatible Hardware | Shining 3D scanners and standard 3D-scan / point-cloud data |
| Operating System | Windows 10 / 11 (64-bit) |
| System Requirements | Quad-core 3 GHz+ CPU · 8 GB RAM min (16 GB rec.) · OpenGL 4.0+ GPU with 2 GB+ VRAM · 30 GB disk |
| Licensing | Perpetual or subscription, multi-seat — request licensing and pricing |
Product videos
Want to try it on your own part?
Start the 14-day trial and we'll walk you through a sample scan-to-CAD job on your own scan — see the parametric result before you license.
Other products teams run alongside Geomagic Design X Reverse Engineering Software – Scan-to-CAD | Parametric Solid Modeling
