Delfin MISTRAL 451 BL D2
The 451 BL D2 is a compact and powerful industrial vacuum cleaner, perfect for general cleaning or for collecting dust. With an NRTL certification for combustible dust in Class II, Divsion 2 environments.
Data Sheet MISTRAL 451 BL D2
Download
- Description
- Additional information
- cross-sell
Description
Technical Features
NRTL Certified for Class II, Divison 2 hazardous locations (Pending) Industrial Applications
- Compact and portable
- Constructed with powder coated steel
- Brushless spark-free motor (average life 15,000 hrs)
- Bonding and grounding
- Removable stainless steel collection tank
- Accessory basket
- Integrated cleaning system
- Performance indicator light
Technical Data
MISTRAL 451 BL D2
Voltage
V – Hz
115 – 60 1~
Power
HP (kW)
2.7 (2.0)
Max Water Lift
inH20 (mmH2O)
90.1 (2289)
Max Airflow
CFM (m³/h)
211.9 (360)
Suction Inlet
in. (mm)
3 (80)
Capacity
Gal. (L)
12 (45)
Noise Level (EN ISO 3744)
dB(A)
76
Dimensions (WxLxH)
in. (cm)
23x25x49 (58x63x125)
Weight
lb. (kg)
121 (55)
Primary Filter Type
Star
Material – Efficiency
IEC 60335-2-69
Polyester – Class ANT M
Filter Surface Area
ft² (m²)
22 (2)
Air load on filter
ft/min (m/h)
9.8 (180)
Cleaning system
DUSTOP
Additional information
| Weight | 121 lbs |
|---|---|
| Dimensions | 23 × 25 × 49 in |
| Weight | 121 (55) |
| Dimensions | 23 x 25 x 49 (58 x 63 x 125) |
| Voltage | 115 V |
| Electric power | 2 kW |
| Max Water Lift | 90.1 in |
| Max Airflow | 211.9 (360) CFM (m³/h) |
| Suction Inlet | 3 in |
| Capacity | 12 gal |
| Noise Level (EN ISO 3744) | 76 dB(A) |
| Primary Filter Type | Star |
| Material - Efficiency | IEC 60335-2-69 Antistatic Polyester – Class M |
| Filter Surface Area | 22 ft² |
| Cleaning system | DUSTOP |
| Air load on filter | 9.8 (180) ft/min (m/h) |
